Item | Unite | CK6146YG | CK6156YG | CK6163YG | CK6171YG | CK6180YG | |
Capacity | Max. Swing dia. over bed | mm | Φ560 | Φ630 | Φ780 | Φ1000 | Φ1050 |
Max. Swing dia. over slide | mm | Φ400 | Φ500 | Φ630 | Φ780 | Φ840 | |
Max workpiece length | mm | 2500 | 1500/2000/3000 | 2000/3000/4000 | 3000/4000/5000 | 3000/4000/5000 | |
Max turning length(cylinder) | mm | 2450 | 1450/1950/2950 | 1950/2950/3900 | 2900/3900/4900 | 2900/3900/4900 | |
Max turning diameter(shaft) | mm | Φ400 | Φ500 | Φ600 | Φ600 | Φ600 | |
Max turning diameter(plate) | mm | Φ480 | Φ600 | Φ630 | Φ780 | Φ780 | |
spindle | spindle through hole | mm | Φ80 | Φ80 | Φ90 | Φ90 | Φ90 |
Spidle inner hole taper | Metric 80# | Metric 80# | Metric 100# | Metric 100# | Metric 100# | ||
spindle nose | A2-8 | A2-8 | A2-11 | A2-11 | A2-11 | ||
spindle rotating speed range, hydraulic two shift stepless | r/min | 30-1200 | 20-1200 | 20-800 | 20-800 | 20-800 | |
main motor power | kW | 15/18.5kw | 18.5/22kw | 22/30kw | 37/42kw | 37/42kw | |
sub-spindle | Sub-spindle movement method | mm | Independent axis servo motor | Independent axis servo motor | Independent axis servo motor | Independent axis servo motor | Independent axis servo motor |
Sub-spindle sleeve diameter/travel | mm | Φ160/100 | Φ190/120 | Φ190/120 | Φ190/120 | Φ190/120 | |
chuck | Front spindle middle solid chuck diameter | mm | Φ250 | Φ315 | Φ400 | Φ500 | Φ610 |
Back spindle middle solid chuck diameter | mm | Φ200 | Φ250 | Φ315 | Φ400 | Φ500 | |
steady rest | Hydraulic steady rest clamp range | mm | Φ50-Φ250 | Φ45-Φ310/Φ85-Φ350/ Φ100-Φ320 | Φ120-Φ400/Φ230-Φ430 | Φ150-Φ500 | Φ300-Φ600 |
repeat position accuracy | mm | 0.01 | 0.01/0.01/0.01 | 0.01/0.01 | 0.01 | 0.01 | |
Tool post | Rapid movement speed (X/Z/W) | m/ min | 10/12/6 | 10/12/6 | 10/12/6 | 10/10/4 | 10/10/4 |
Travel (X/Z) | mm | 245/2500 | 315/3000 | 315/4000 | 350/5000 | 350/5000 | |
(X/Z/W) Motor torque | Nm | 11/16/11 | 22/30/12 | 22/30/12 | 22/30/12 | 22/30/12 | |
Tool post cutting tool station | 12 | 12 | 12 | 12 | 12 | ||
Outside diameter cutting tool | mm | 25×25 | 32×32 | 32×32 | 32×32 | 32×32 | |
Inner diameter cutting tool | mm | Φ50 | Φ60 | Φ60 | Φ60 &Φ80 | Φ60 &Φ80 | |
accuracy | Machining accuracy | IT6 | IT6 | IT6 | IT6 | IT6 | |
Roughness Ra | μm | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | |
Position accuracy | mm | 0.014/0.036 | 0.014/0.036 | 0.014/0.038 | 0.015/0.040 | 0.016/0.040 | |
Repeat position accuracy | mm | 0.006/0.018 | 0.006/0.018 | 0.007/0.018 | 0.007/0.020 | 0.007/0.020 | |
Weight and overall dimension | Net weight/gross weight | t | 13.5 | 18/20/22 | 22/25/28 | 28/32/34 | 28/32/36 |
Overall dimension(L*W*H) | mm | 6500×1750×1860 | 6700×2350× 2600 | 7150×2450×2650 | 7150×2550×2600 | 7150×2550×2600 | |
The remarkable quality, perfect faith, and endless pursuit cause our Special Designed CNC Lathe for Machining Oil Industry Part (CK61160) form a strong comprehensive strength in the marketplace. The company always adheres to the concept of "pursuing superior quality and inheriting a long history", and sincerely looks forward to sincere cooperation and common development with new and old customers at home and abroad. In order to improve the quality and safety of products, the company starts from the source and strictly monitors and manages production.
