Oil Cylinder Special Machine High Accuracy CNC Lathe Ck6163yg

After years of development, our company's business has spread all over the world, becoming one of the Double Axis Deep Hole Gun Drilling Machine, High Precision CNC Lathe, CKD D Series High Precision CNC Lathe 6Tons Load suppliers with excellent prices, sufficient supply and large inventory. We will continue to pay attention to the company's strategic direction and profit growth, which will further advance our leading position in the market. We invites you and your company to thrive together with us and share a dazzling foreseeable future in world-wide market place.

Oil Cylinder Special CNC Lathe

Item		Unite	CK6146YG	CK6156YG	CK6163YG	CK6171YG	CK6180YG
Capacity	Max. Swing dia. over bed	mm	Φ560	Φ630	Φ780	Φ1000	Φ1050
	Max. Swing dia. over slide	mm	Φ400	Φ500	Φ630	Φ780	Φ840
	Max workpiece length	mm	2500	1500/2000/3000	2000/3000/4000	3000/4000/5000	3000/4000/5000
	Max turning length(cylinder)	mm	2450	1450/1950/2950	1950/2950/3900	2900/3900/4900	2900/3900/4900
	Max turning diameter(shaft)	mm	Φ400	Φ500	Φ600	Φ600	Φ600
	Max turning diameter(plate)	mm	Φ480	Φ600	Φ630	Φ780	Φ780
spindle	spindle through hole	mm	Φ80	Φ80	Φ90	Φ90	Φ90
	Spidle inner hole taper		Metric 80#	Metric 80#	Metric 100#	Metric 100#	Metric 100#
	spindle nose		A2-8	A2-8	A2-11	A2-11	A2-11
	spindle rotating speed range, hydraulic two shift stepless	r/min	30-1200	20-1200	20-800	20-800	20-800
	main motor power	kW	15/18.5kw	18.5/22kw	22/30kw	37/42kw	37/42kw
sub-spindle	Sub-spindle movement method	mm	Independent axis servo motor	Independent axis servo motor	Independent axis servo motor	Independent axis servo motor	Independent axis servo motor
sub-spindle	Sub-spindle sleeve diameter/travel	mm	Φ160/100	Φ190/120	Φ190/120	Φ190/120	Φ190/120
chuck	Front spindle middle solid chuck diameter	mm	Φ250	Φ315	Φ400	Φ500	Φ610
chuck	Back spindle middle solid chuck diameter	mm	Φ200	Φ250	Φ315	Φ400	Φ500
steady rest	Hydraulic steady rest clamp range	mm	Φ50-Φ250	Φ45-Φ310/Φ85-Φ350/ Φ100-Φ320	Φ120-Φ400/Φ230-Φ430	Φ150-Φ500	Φ300-Φ600
steady rest	repeat position accuracy	mm	0.01	0.01/0.01/0.01	0.01/0.01	0.01	0.01
Tool post	Rapid movement speed (X/Z/W)	m/ min	10/12/6	10/12/6	10/12/6	10/10/4	10/10/4
	Travel (X/Z)	mm	245/2500	315/3000	315/4000	350/5000	350/5000
	(X/Z/W) Motor torque	Nm	11/16/11	22/30/12	22/30/12	22/30/12	22/30/12
	Tool post cutting tool station		12	12	12	12	12
	Outside diameter cutting tool	mm	25×25	32×32	32×32	32×32	32×32
	Inner diameter cutting tool	mm	Φ50	Φ60	Φ60	Φ60 &Φ80	Φ60 &Φ80
accuracy	Machining accuracy		IT6	IT6	IT6	IT6	IT6
	Roughness Ra	μm	1.6	1.6	1.6	1.6	1.6
	Position accuracy	mm	0.014/0.036	0.014/0.036	0.014/0.038	0.015/0.040	0.016/0.040
	Repeat position accuracy	mm	0.006/0.018	0.006/0.018	0.007/0.018	0.007/0.020	0.007/0.020
Weight and overall dimension	Net weight/gross weight	t	13.5	18/20/22	22/25/28	28/32/34	28/32/36
Weight and overall dimension	Overall dimension(LWH)	mm	6500×1750×1860	6700×2350× 2600	7150×2450×2650	7150×2550×2600	7150×2550×2600

We do every detail carefully, continuously improve the quality of Oil Cylinder Special Machine High Accuracy CNC Lathe Ck6163yg and services, and pursue customer experience. We strive to achieve harmony with nature and benefit society in order to provide support for the benign progress of society. In order to achieve positive and sustainable development of the enterprise, we continue to increase investment in technology research and development.
