item | CK6156 | CK6156D | CK6163 | CK6180 | CK61100 | CK61125 | |
max swing over bed | Φ560 | Φ560 | Φ630 | Φ800 | Φ1000 | Φ1250 | |
max swing over slide | Φ400 | Φ400 | Φ500 | Φ630 | Φ700 | Φ800 | |
Max workpiece length | 750/1000/1500/ 2000/3000 | 750/1000/1500/ 2000/3000 | 750/1000/1500/ 2000/3000 | 750/1000/1500/ 2000/3000 | 1500/2000 /3000 | 1500/3000 | |
Max turning workpiece lenghth | 750/1000/1500/ 2000/3000 | 750/1000/1500/ 2000/3000 | 750/1000/1500/ 2000/3000 | 750/1000/1500/ 2000/3000 | 1500/2000/ 3000 | 1500/3000 | |
max turning diameter axial type | Φ320 | Φ320 | Φ500 | Φ600 | Φ700 | Φ800 | |
max turning diameter plate type | Φ400 | Φ400 | Φ630 | Φ700 | Φ800 | Φ1000 | |
mm spindle inner hole | Φ72 | Φ80 | Φ90 | Φ90 | Φ140 | Φ140 | |
spindle inner hole taper | metric80 | metric100 | metric100 | metric120 | metric120 | metric160 | |
spindle head nose | A2-8 | A2-8 | A2-8 | A2-11 | A2-11 | A2-15 | |
item | CK6156 | CK6156D | CK6163 | CK6180 | CK61100 | CK61125 | |
spindle rotating speed range | stepless r/min | 50-3000 - | - | - | - | - | - |
two shift+stepless | - | 50-1200 | 50~1000 | 50~800 | 50~800 | 50-650 | |
kW main motor power | 15 | 15 | 22 | 30 | 37 | 37 | |
(standard) mm chuck inner solid | Φ312 | Φ312 | Φ400 | Φ500 | Φ500 | Φ630 | |
(optional )mm hydraulic chuck inner hollow | Φ312/55 | Φ312/55 | Φ400/75 | Φ500/75 | Φ500/85 | Φ630/100 | |
mm Tailstock sleeve diameter | Φ110 | Φ110 | Φ120 | Φ120 | Φ170 | Φ200 | |
mm Tailstock sleeve moving distance | 100 | 100 | 120 | 120 | 170 | 200 | |
Tailstock sleeve inner hole taper | Morse5# | Morse5# | Morse6# | Morse6# | Morse6# | Morse6# | |
Item | CK6156 | CK6156D | CK6163 | CK6180 | CK61100 | CK61125 | |
m/min Rapid moving linner rolling guideway | 12/16 | - | - | - | - | 10/12 | |
m/min the rectangular slide guideway | - | 10/10 | 10/10 | 10/10 | 10/10 | - | |
mm max tool post travel | 230/800 | 230/800 | 325/800 | 360/800 | 415/1550 | 615/1550 | |
(X/Z)Nm motor torque | 12/22 | 12/22 | 22/22 | 22/22 | 30/30 | 30/30 | |
tool post capacity | 12 | 12 | 12 | 12 | 12 | 8 | |
tool cross area mm | 25×25 | 25×25 | 32×32 | 32×32 | 32×32 | 32×32 | |
mm tool inner diameter | Φ40 | Φ40 | Φ50 | Φ60 | Φ80 | Φ80 | |
the machining accuracy | IT6 | IT6 | IT6 | IT6 | IT6 | IT6 | |
Raμm roughness | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | |
Item | CK6156 | CK6156D | CK6163 | CK6180 | CK61100 | CK61125 | |
(X/Z)mm min set unit | 0.001 | 0.001 | 0.001 | 0.001 | 0.001 | 0.001 | |
(X/Z)mm position accuracy | 0.01/0.012 | 0.01/0.012 | 0.012/0.015 | 0.012/0.015 | 0.012/0.020 | 0.012/ 0.015 | |
(X/Z)mm repeat position accuracy | 0.006/0.008 | 0.006/0.008 | 0.007/0.01 | 0.007/0.01 | 0.007/0.012 | 0.010/ 0.012 | |
net weight | 7000 | 7000 | 8000 | 8000 | 15000 | 20000 |
